AC and AC+DC voltage measurements with selectable digital low pass filter for accurate voltage and frequency readings on variable frequency drives
Also measures DC voltage, resistance, capacitance, temperature and frequency
Tests continuity and diodes
Low impedance AutoCheck™ mode automatically selects AC or DC volts, resistance or continuity. Low impedance masks "ghost" voltage pickup
Backlight & relative mode for added versatility
Two voltage detection modes - non-contact or using a single test lead
Computer interface capability using optional CMSC-1U cable and software
Data hold
Crest (peak hold) feature captures current or voltage peaks as short as 5 milliseconds
Lifetime warranty
Specifications
Amperage Measurement
200, 2000 Amps AC+DC
Display
LCD with dual measurements. 6000 counts for current, voltage, resistance, temperature and capacitance. 2000 counts for frequency
Frequency Rating
40 to 400 Hz
Includes
(2) 1.5V AA batteries, test leads, carrying case
Jaw Opening
2.1'' (55 mm)
Measurement Category
CAT IV 1000V
Replacement Part
TSG-3 Test Leads, TC-30 Carrying Case
Resistance Measurement
600, 6k, 60k, 600k, 6M, 40M Ohms
Standard
CAT IV, C/US UL Listed, CE
True Power
AC+DC True RMS
Voltage Measurement
6, 60, 600, 1000 Volts AC+DC
*Greenlee® may make improvements and/or changes in the specifications of products at any time, in its sole discretion, without notice or obligation and further reserves the right to change or discontinue models.
