AC and AC+DC voltage measurements with digital low pass filter for accurate readings on variable frequency drives
Also measures DC voltage, resistance, capacitance and frequency
Tests continuity and diodes
Peak-RMS measures motor inrush current
Backlight & relative mode for added versatility
AmpTip™ increases accuracy on small wires and low current
Two voltage detection modes - non-contact or using a single test lead
Data hold
Recording of Maximum, Minimum, and Average readings
Lifetime warranty
Specifications
Amperage Measurement
60, 600 Amps AC+DC
Display
LCD, 6000 Count
Frequency Rating
Voltage and AmpTip™ current: 50/60 Hz. High current: 50 to400 Hz
Includes
(2) 1.5V AAA batteries, test leads, carrying case
Jaw Opening
1.18'' (30 mm)
Measurement Category
CAT III 600V, CAT IV 300V
Replacement Part
TSG-3 test leads, TC-10 carrying case
Resistance Measurement
600, 6k, 60k Ohms
Standard
CAT III, C/US UL Listed, CE
True Power
AC+DC True RMS
Voltage Measurement
600 Volts AC+DC
*Greenlee® may make improvements and/or changes in the specifications of products at any time, in its sole discretion, without notice or obligation and further reserves the right to change or discontinue models.
