Cablematic QCST 500T-R Ratcheting Quick Change Coring/Stripping Tool - Red body

QCST

Quick Change Coring / Stripping Tool

• ALL-IN-ONE, accurately strips the jacket, cores the dielectric, strips and bevels the aluminum sheath
• NEW DESIGN conveniently attaches the jacket stripper body (QJST) to the main body of the coring and stripping tool using a “QUICK-CHANGE” rotating body ring
• QJST color coded JACKET STRIPPING BODY is removed and used in a 2 STEP OPERATION WHEN USING FLOODED CABLES.
  STEP 1 – Remove the jacket with the removable QJST. STEP 2 – Remove flooding compound from cable and use the QCST coring and stripping tool body to complete the preparation
• Jacket stripping body (QJST), when used separately to remove the jacket on flooded cable, is uniquely designed to automatically provide 3.50 in. (88.9 mm) of jacket removal when rotated to the end of the body
• Jacket stripper body and coring / stripping tool guide sleeve are all COLOR CODED for easy cable identification
• CHAMFERED STRIP STOP - 1 in. (25.4 mm) stop -  is factory installed
• Pre-set jacket blade assures no scoring or nicking of aluminum sheath
• MANUAL or DRILL operation;
  QCST-R tools have a RATCHET “T” handle and a separate 3/8 in. (9.5 mm) drill adapter
• Rugged, durable, ALL-METAL construction
• Heat treated sheath cutting blade produces a smooth beveled edge and can be replaced without the expense of replacing the entire coring bit
• Spiral-fluted, heat treated steel bit
• Use of CC-200EUR Center Conductor Cleaner / Scraper (SKU: 262347) removes residual dielectric which remains on the conductor after coring and stripping

Specifications

• Made in the U.S.A
•  Length: 8.1 in. (205.7 mm)
•  Weight: 1 lb 4 oz (525 g)
