PRODEX UV9 LED Handheld Wand 10W

SKU #578200
Broad spectrum (UV: 365nm & 385nm, VIS: 405nm & 420nm) allows co-optimisation of adhesives and curing system for best results. UV9 is intended for use in industrial environments such as workshops, assembly lines and laboratories.
  • Price was previously advertised incorrectly at $830 AUD when it should have been $830 USD. Apologies for the error.
AU$1,276.92 AU$1,404.61
Availability: In stock
Part Number
578200

Features

  • Broad spectrum offered UV: 365nm & 385nm, VIS: 405nm & 420nm
  • Adjustable high intensity up to 1,800mW/cm²
  • Handheld and easily portable
  • Instant ON/OFF, no warm-up period
  • Built-in intensity check indicator
  • Cartridge battery

Applications

  • Broadband LEDs for use in workshops, assembly lines and laboratories.

Specifications

Wand

  • Light source: High power 10W LEDs ( average lifespan is 2,000 hours)
  • Wavelength: Peak: 365,385,405,420nm
  • Radiant intensity: Up to 1,800mW/cm²
  • Light guide rod: Ø11>11mm optical fiber, Sterilizable in autoclave (max. T. 135℃ for 20 minutes)
  • Dimension: Ø38mm (max.) x L190mm
  • Weight: 180g (with battery and light guide rod)

Power Supply

  • Type: Micro USB jack
  • Input: 100~240V, 50~60Hz
  • Output: DC 5V/2A

Cradle

  • Weight: 140g
  • Dimension: Ø115 x H68 mm

Battery

  • Type: Lithium-ion, 3.7V/ 2,500mAh
  • Charging time: About 2.5 hours
  • Use time: 113 minutes ( 680 times in 10 Sec. Entire mode/ High intensity)

Accessories and Spare Parts Available

DENTMATE REF DENTMATE accessories
1320-1001 UV9 Wand
1320-2001 Cradle
1212-0030 Filter
1212-0059 Carrying Case
2101-0024 Battery (3.7V/ 2500mAh)
2102-0007 11-11mm Light Guide
2405-0002 Anti-glare Shield
2409-0006 Goggles (Orange)
More Information
Manufacturer PRODEX
Product Series PRODEX UV9 LED Wands
Product Type UV and LED Curing Devices
Size / Operation Handheld
Case Included Available Seperately
Device Connectivity via USB
Applications Advanced Testing, Inspection and Measurement Applications
Standard Package Contains
Warranty 1 Year
Warranty Notes AusOptic Genuine Product Guarantee
Authorised distributor, benefit from manufacturer-backed, local warranty coverage, genuine parts, and our experienced local support team
