NTT-AT ADS Films and ADS Rubber - Improve your polishing costs & performance

Improve your Polishing Performance and Cost with the Best Film.

Ideal for final polishing
It will not scratch or damage the end-face when polishing. Also, binders and silica particles from the film will not stick on the ferrule during the polishing process. For single modes, it can achieve a polishing level of super-low return loss amount(UPC) at 55dB. 　　　　　　　　　　　　
Outstanding Final Polishing　Performance and Longevity 　　　　　　　　When used with the new ADS Rubber developed for the ADS Film, it will last longer than before(the current rubbers can still be used). 　　　　　　　　　　　　
International Standard for Final Polishing 　　　　　　　　Ferrule/Connector Manufacturers worldwide have been using the ADS films due to the cost efficiency and performance.

Size	Disk type: 127mm(5 in.) dia
Color	ADS：Colorless Translucent
Base Thickness	75μm（3mil）
Compatible Ferrules	2.5mm zirconia ferrule 1.25mm zirconia ferrule
Storage Condition	Temperature: 10~30℃、Humidity: 30~60%

Size	Disk type: φ127mm(5inch), Thickness: 5mm
Color	Black( has a NTT-AT mark on the back)
Hardness (HS)	65,70,80,85
Compatible Ferrules	2.5mm zirconia ferrule 1.25mm zirconia ferrule
Storage Condition	Temperature: 10~30℃、Humidity: 30~60%

NTT-AT is looking for companies that can evaluate our ADS Films and ADS Rubber. We will give out free samples to companies that are interested.

＊Details needed on the evaluation report
