OST iConverter 2FXM2 100M SFP to SFP F/O Converter Wallmount w/ Mgmt

Omnitron Systems 100BASE-FX SFP to 100BASE-FX SFP Media Converter and Network Interface Device - Fast Ethernet - 100Base-FX, 100Base-X, 100Base-LX, 100Base-ZX, 100Base-BX - 2.0 x Expansion Slots - SFP - AC Adapter - Wall Mountable, Standalone - TAA Compliant

The iConverter 2FXM2 is a carrier-grade Network Interface Device (NID) that provides Fast Ethernet fibre to fibre media conversion with integrated management.

For Service Providers, the 2FXM2 NID provides MEF 9, 14 and 21 certified demarcation of Carrier Ethernet E-Line services. The 2FXM2 is a cost-effective demarcation device for Service Providers to deliver best-effort Ethernet services.

For Enterprise and Government and Utility networks, the 2FXM2 enables secure demarcation and management for mission-critical applications delivered over fibre infrastructure.

IEEE 802.3ah Operations, Administration and Maintenance

The 2FXM2 supports the IEEE 802.3ah Link OAM standard with Fault Detection, Performance Monitoring and Remote Loopback for Ethernet in the First Mile (EFM) access links.

Fault Detection
The 2FXM2 detects and indicates link faults, dying gasp and other critical events. Dying gasp is supported on all standalone models and plug-in models when installed in a 1-Module or 2-Module chassis with dying gasp support. The 2FXM2 also supports Unidirectional Link Fault Detection that indicates faults in either direction of the fibre link.

Performance Monitoring
802.3ah Performance Monitoring tools are used for the detection and notification of link performance (quality) faults. Ethernet data performance can deteriorate slowly over time, and the 2FXM2 allows the setting of error-per-second thresholds with event notification for early indication of issues that may be resolved prior to loss of service.

Remote Loopback
Remote Loopback is used for fault localization and link performance testing. When a 2FXM2 port is in loopback mode, all received link traffic is looped back and transmitted back unaltered. The statistics from the 2FXM2 port and the remote link partner can be compared for consistency.

VLAN with 802.1ad Q-in-Q and QoS for E-Line services
The iConverter 2FXM2 supports the IEEE 802.1Q tag Virtual Local Area Network (VLAN) packet tagging and untagging (including Q-in-Q tunneling and 802.1ad service provider tag) and the 802.1p Quality of Service priority standards. VLAN 802.1ad tunneling technology enables service providers to offer their customers E-Line services via Ethernet Virtual Circuits (EVC). The 802.1p Quality of Service (QoS) prioritization standard enables delivery of high-priority, real-time applications such as voice and video over Ethernet.

Port Bandwidth Control and Port Access Control
The enhanced Bandwidth Control feature controls bandwidth between the fibre ports in 64Kbps increments from 64K to Full Line Speed. The 2FXM2 features Port Access Control which blocks user service while maintaining the network link. Port Access Control enables the service provider to control user access while maintaining port configuration for easy disabling or enabling of customer service. Port Access Control provides enterprise administrators the capability to improve network security by controlling port access when the port is not in use.
