FLEXOPTIX 622M SFP STM-4 | 120 km, λ1550 nm, DDM, LC-Duplex, Singlemode

SKU #S.1506.B.D
  • Universal SONET / SDH SFP Transceiver
  • Use FLEXBOX to configure to almost any vendor
  • Capable of operating in SDH / SONET networks
  • Supported Data Rates: 125 Mbit/s - 622 Mbit/s
  • Up to 120 km via Singlemode OS2
  • LC-Duplex Connector
  • Digital Diagnostic Monitoring (DDM)
AU$186.87 AU$205.56
Confirm stocks / Dispatched from Germany (7 days)
Part Number
S.1506.B.D
More Information
Manufacturer FLEXOPTIX
Product Series FLEXOPTIX Universal Transceivers
Product Type Transceivers
Form Factor SFP
Connector LC-Duplex PC
Distance 120 km
Interface STM-4
Wavelength TX 1550 nm
Power Budget (dB) 34 dB
Extinction Ratio 10 dB
Bandwidth Range 125 Mbit/s - 622 Mbit/s
Laser DFB
Receiver Type PIN
Wavelength RX (Range) 1260 - 1600 nm
Temperature Range 0°C - 70°C
Type of DDM / DOM Yes, internally calibrated
Networking Protocol Fast Ethernet, STM-1, STM-4
Vendor Switch Coding MSA Standard, Cisco Systems, Marconi
CDR none
Inbuilt FEC No
Receiver Min/Max -32 dBm / -10 dBm (overload)
SGMII No
Transmit Min/Max 2 dBm / 7 dBm
Power Consumption 1 W
Modulation NRZ
Industry Telecommunications, Carriers, Service and Content Providers, Campus Networks, Data Centres, Enterprise Networks
Applications Data Centre Connectivity, GPON (Gigabit Passive Optical Network), LAN Installation, Network Core and Edge, SFP/Transceiver Vendor Programming, RF and microwave photonics, Carriers, Service and Content Providers, Enterprise Networking
Warranty 1 Year
Warranty Notes AusOptic Genuine Product Guarantee
Authorised distributor, benefit from manufacturer-backed, local warranty coverage, genuine parts, and our experienced local support team
