FLEXOPTIX 3G Video SDI SFP | 50 km, λ1550 nm, DDM, LC-Duplex, SM 1.2 W

SKU #S.1530.50.D
AU$461.79 AU$507.97
Reordering - Contact to confirm availability
Part Number
S.1530.50.D
More Information
Manufacturer FLEXOPTIX
Product Series FLEXOPTIX Universal Transceivers
Product Type Transceivers
Form Factor SFP
Connector LC-Duplex PC
Distance 50 km
Interface 3G SDI
Wavelength TX 1550 nm
Power Budget (dB) 18 dB
Extinction Ratio 5 dB
Bandwidth Range 270 Mbit/s - 2.97 Gbit/s
Laser DFB
Receiver Type PIN
Wavelength RX (Range) 1270 - 1610 nm
Temperature Range 0°C - 70°C
Type of DDM / DOM Yes, internally calibrated
Networking Protocol 3G SDI
Vendor Switch Coding MSA Standard
CDR none
Inbuilt FEC No
Receiver Min/Max -18 dBm / -3 dBm (overload)
SGMII No
Transmit Min/Max 0 dBm / 3 dBm
Power Consumption 1.2 W
Modulation NRZ
Industry Telecommunications, Carriers, Service and Content Providers, Campus Networks, Data Centres, Enterprise Networks
Applications Data Centre Connectivity, GPON (Gigabit Passive Optical Network), LAN Installation, Network Core and Edge, SFP/Transceiver Vendor Programming, RF and microwave photonics, Carriers, Service and Content Providers, Enterprise Networking
Warranty 1 Year
Warranty Notes AusOptic Genuine Product Guarantee
Authorised distributor, benefit from manufacturer-backed, local warranty coverage, genuine parts, and our experienced local support team
