FLEXOPTIX 3G Video SDI SFP | 10 km, 2x λ1310 nm, DDM, LC-Duplex, Singlemode

Be the first to review this product

SKU #S.1330.DT.10.DN

Video SFP Transceiver
3G SDI protocol support for broadcasting applications
Dual Transmitter - no Receiver
NON-MSA electrical pinout
Supported Data Rates: 100 Mbit/s - 6 Gbit/s
Up to 10 km via Singlemode OS2
LC-Duplex Connector
Digital Diagnostic Monitoring (DDM)

AU$545.20 AU$599.72

Reordering - Contact to confirm availability

Part Number

S.1330.DT.10.DN

More Information

Reviews

Product Questions

More Information
Manufacturer	FLEXOPTIX
Product Series	FLEXOPTIX Universal Transceivers
Product Type	Transceivers
Form Factor	SFP
Connector	LC-Duplex PC
Distance	10 km
Interface	3G SDI
Wavelength TX	2x 1310 nm
Extinction Ratio	7.5 dB
Bandwidth Range	100 Mbit/s - 6 Gbit/s
Laser	FP
Temperature Range	0°C - 70°C
Type of DDM / DOM	Yes, internally calibrated
Networking Protocol	3G SDI
Vendor Switch Coding	MSA Standard
CDR	none
Inbuilt FEC	No
Bandwidth Per Lane	50 Mbit/s - 3 Gbit/s
Receiver Min/Max	TX only
SGMII	No
Transmit Min/Max	-5 dBm / 0 dBm
Power Consumption	1 W
Lane Count	2x (Tx only)
Modulation	NRZ
Industry	Telecommunications, Carriers, Service and Content Providers, Campus Networks, Data Centres, Enterprise Networks
Applications	Data Centre Connectivity, GPON (Gigabit Passive Optical Network), LAN Installation, Network Core and Edge, SFP/Transceiver Vendor Programming, RF and microwave photonics, Carriers, Service and Content Providers, Enterprise Networking
Warranty	1 Year
Warranty Notes	AusOptic Genuine Product Guarantee Authorised distributor, benefit from manufacturer-backed, local warranty coverage, genuine parts, and our experienced local support team
