FLEXOPTIX 32G Fibre Channel SFP28 Industrial with dual CDR | 10 km, λ1310 nm, LC-Duplex, Singlemode

SKU #P.1332G.10.I

Universal Fibre Channel SFP28 Transceiver
Use FLEXBOX to configure to almost any vendor
Fibre Channel (FC) support for storage area network (SAN) interconnect
Integrated Clock-Data-Recovery (CDR)
Supported Data Rates: 25.78 Gbit/s - 28.05 Gbit/s
Up to 10 km via Singlemode OS2
LC-Duplex Connector
Operating Temperature from -40&C to 85&C

AU$431.21 AU$474.33

Reordering - Contact to confirm availability

Part Number

P.1332G.10.I

More Information
Manufacturer	FLEXOPTIX
Product Series	FLEXOPTIX Universal Transceivers
Product Type	Transceivers
Form Factor	SFP28
Connector	LC-Duplex PC
Distance	10 km
Interface	32G FC LW
Wavelength TX	1310 nm
Power Budget (dB)	8.3 dB
Transmit and Dispersion Penalty	2.7 dB
Extinction Ratio	3.5 dB
Laser	DFB
Receiver Type	PIN
Type of DDM / DOM	Yes, internally calibrated
Vendor Switch Coding	MSA Standard, Brocade, Cisco Systems
Modulation	NRZ
CDR	TX and RX
Inbuilt FEC	No
Receiver Min/Max	-13.3 dBm / 2 dBm (overload)
SGMII	No
Transmit Min/Max	-5 dBm / 2 dBm
Wavelength RX (Range)	1260 - 1370 nm
Power Consumption	1.5 W
Bandwidth Range	25.78 Gbit/s - 28.05 Gbit/s
Industry	Telecommunications, Carriers, Service and Content Providers, Campus Networks, Data Centres, Enterprise Networks
Applications	Data Centre Connectivity, GPON (Gigabit Passive Optical Network), LAN Installation, Network Core and Edge, SFP/Transceiver Vendor Programming, RF and microwave photonics, Carriers, Service and Content Providers, Enterprise Networking
Networking Protocol	25G Ethernet, 32G Fibre Channel
Temperature Range	-40°C - 85°C
Standard Package Contains
Warranty	1 Year
Warranty Notes	AusOptic Genuine Product Guarantee Authorised distributor, benefit from manufacturer-backed, local warranty coverage, genuine parts, and our experienced local support team
