FLEXOPTIX 2x 1G CSFP BiDi EX | 40 km, 2x ᵀˣ1310 / 2x ᴿˣ1490 nm, DDM, LC-Simplex, Singlemode

SKU #S.C1612.40.CL
  • Universal CSFP Dual BiDi Transceiver
  • Use FLEXBOX to configure to almost any vendor
  • Double your devices port density - one transceiver two applications
  • For 1000BASE-EX Ethernet links
  • Supported Data Rates: 2x 120 Mbit/s - 2x 1.25 Gbit/s
  • Up to 40 km via Singlemode OS2
  • 2x LC-Simplex Connector
  • Digital Diagnostic Monitoring (DDM)
AU$267.87 AU$294.66
Reordering - Contact to confirm availability
Part Number
S.C1612.40.CL
More Information
Manufacturer FLEXOPTIX
Product Series FLEXOPTIX Universal Transceivers
Product Type Transceivers
Form Factor CSFP
Connector 2x LC-Simplex UPC
Distance 40 km
Interface 2x BiDi EX
Wavelength TX 2x 1310 nm
Power Budget (dB) 21 dB
Transmit and Dispersion Penalty 1 dB
Extinction Ratio 6 dB
Bandwidth Range 2x 120 Mbit/s - 2x 1.25 Gbit/s
Laser DFB
Receiver Type PIN
Temperature Range 0°C - 70°C
Type of DDM / DOM Yes, internally calibrated
Networking Protocol Fast Ethernet, Gigabit Ethernet
Vendor Switch Coding MSA Standard, Cisco Systems
CDR none
Inbuilt FEC No
Bandwidth Per Lane 120 Mbit/s - 1.25 Gbit/s
Receiver Min/Max -24 dBm / -3 dBm (overload)
SGMII No
Transmit Min/Max -3 dBm / 2 dBm
Power Consumption 1.5 W
Lane Count 2x (Tx/Rx)
Modulation NRZ
Industry Telecommunications, Carriers, Service and Content Providers, Campus Networks, Data Centres, Enterprise Networks, Financial Institutions, Government and Defence Communications, Aerospace and Defence, Broadcast, Mining, Off-shore and Remote, Security, Transportation, Utilities
Applications GPON (Gigabit Passive Optical Network), Last Mile, LAN Installation, Network Infrastructure, Network Core and Edge
Standard Package Contains
Warranty 1 Year
Warranty Notes AusOptic Genuine Product Guarantee
Authorised distributor, benefit from manufacturer-backed, local warranty coverage, genuine parts, and our experienced local support team
