FLEXOPTIX 25G SFP28 ER Industrial with dual CDR | 40 km, λ1300 nm, LC-Duplex, Singlemode
SKU #P.1325G.40.I
- Universal SFP28 Transceiver
- Use FLEXBOX to configure to almost any vendor
- For 25GBASE-ER Ethernet links
- Integrated Clock-Data-Recovery (CDR)
- Reach up to 30km (w/o FEC) or 40km (w/ FEC) over G.652 SMF
- Supported Data Rates: 25.78 Gbit/s
- Up to 40 km via Singlemode OS2
- LC-Duplex Connector
- Operating Temperature from -40&C to 85&C
AU$1,119.79
AU$1,231.77
Confirm stocks / Dispatched from Germany (7 days)
Part Number
P.1325G.40.I
| Manufacturer | FLEXOPTIX |
|---|---|
| Product Series | FLEXOPTIX Universal Transceivers |
| Product Type | Transceivers |
| Form Factor | SFP28 |
| Connector | LC-Duplex PC |
| Distance | 40 km |
| Interface | ER |
| Wavelength TX | 1300 nm |
| Power Budget (dB) | 16 dB |
| Transmit and Dispersion Penalty | 4 dB |
| Extinction Ratio | 2.7 dB |
| Laser | EML |
| Receiver Type | APD |
| Type of DDM / DOM | Yes, internally calibrated |
| Vendor Switch Coding | MSA Standard |
| Modulation | NRZ |
| CDR | TX and RX |
| Inbuilt FEC | No |
| Receiver Min/Max | -19 dBm / -4 dBm (overload) |
| SGMII | No |
| Transmit Min/Max | -3 dBm / 6 dBm |
| Wavelength RX (Range) | 1295 - 1325 nm |
| Power Consumption | 1.8 W |
| Bandwidth Range | 25.78 Gbit/s |
| Industry | Telecommunications, Carriers, Service and Content Providers, Campus Networks, Data Centres, Enterprise Networks |
| Applications | Data Centre Connectivity, GPON (Gigabit Passive Optical Network), LAN Installation, Network Core and Edge, SFP/Transceiver Vendor Programming, RF and microwave photonics, Carriers, Service and Content Providers, Enterprise Networking |
| Networking Protocol | 25G Ethernet |
| Temperature Range | -40°C - 85°C |
| Standard Package Contains | |
| Warranty | 1 Year |
| Warranty Notes | AusOptic Genuine Product Guarantee Authorised distributor, benefit from manufacturer-backed, local warranty coverage, genuine parts, and our experienced local support team |
