FLEXOPTIX 200G QSFP56 FR4 with dual CDR | 2 km, λ1271-1331 nm, LC-Duplex, Singlemode

SKU #Q.162HG.2.C
  • Universal QSFP56 Transceiver
  • Use FLEXBOX to configure to almost any vendor
  • For 200GBASE-FR4 Ethernet links
  • Integrated Clock-Data-Recovery (CDR)
  • PAM4 modulated signal
  • Supported Data Rates: 212.5 Gbit/s
  • Up to 2 km via Singlemode OS2
  • LC-Duplex Connector
AU$1,511.80 AU$1,662.98
Reordering - Contact to confirm availability
Part Number
Q.162HG.2.C
More Information
Manufacturer FLEXOPTIX
Product Series FLEXOPTIX Universal Transceivers
Product Type Transceivers
Form Factor QSFP56
Connector LC-Duplex PC
Distance 2 km
Interface FR4
Wavelength TX 1271 nm|1291 nm|1311 nm|1331 nm
Power Budget (dB) 4 dB
Transmit and Dispersion Penalty 3.3 dB
Extinction Ratio 3.5 dB
Laser EML
Receiver Type PIN
Type of DDM / DOM Yes, internally calibrated
Vendor Switch Coding MSA Standard
Lane Count 4x (Tx/Rx)
Modulation PAM4
CDR TX and RX
Inbuilt FEC No
Bandwidth Per Lane 53.13 Gbit/s
Receiver Min/Max -8.2 dBm / 4.7 dBm (overload)
SGMII No
Transmit Min/Max -4.2 dBm / 4.7 dBm
Power Consumption 6.5 W
Bandwidth Range 212.5 Gbit/s
Industry Telecommunications, Carriers, Service and Content Providers, Campus Networks, Data Centres, Enterprise Networks
Applications Data Centre Connectivity, GPON (Gigabit Passive Optical Network), LAN Installation, Network Core and Edge, SFP/Transceiver Vendor Programming, RF and microwave photonics, Carriers, Service and Content Providers, Enterprise Networking
Networking Protocol 200G Ethernet
Temperature Range 10°C - 60°C
Standard Package Contains
Warranty 1 Year
Warranty Notes AusOptic Genuine Product Guarantee
Authorised distributor, benefit from manufacturer-backed, local warranty coverage, genuine parts, and our experienced local support team
