FLEXOPTIX 2.67G SFP STM-16 Industrial | 550 m, λ850 nm, DDM, LC-Duplex, Multimode

SKU #S.8526.02.DI
  • Universal SONET / SDH SFP Transceiver
  • Use FLEXBOX to configure to almost any vendor
  • Capable of operating in SDH / SONET networks
  • Supported Data Rates: 125 Mbit/s - 2.67 Gbit/s
  • Up to 550 m via Multimode OM3
  • LC-Duplex Connector
  • Operating Temperature from -40&C to 85&C, Digital Diagnostic Monitoring (DDM)
AU$64.78 AU$71.26
10 In-stock / Dispatched from Germany (7 days)
Part Number
S.8526.02.DI
More Information
Manufacturer FLEXOPTIX
Product Series FLEXOPTIX Universal Transceivers
Product Type Transceivers
Form Factor SFP
Connector LC-Duplex PC
Distance 550 m
Interface STM-16
Wavelength TX 850 nm
Power Budget (dB) 8 dB
Extinction Ratio 9 dB
Bandwidth Range 125 Mbit/s - 2.67 Gbit/s
Laser VCSEL
Receiver Type PIN
Wavelength RX (Range) 760 - 860 nm
Temperature Range -40°C - 85°C
Type of DDM / DOM Yes, internally calibrated
Networking Protocol Fast Ethernet, 1G Fibre Channel, 2G Fibre Channel, Gigabit Ethernet, STM-1, STM-4, STM-16
Vendor Switch Coding MSA Standard, Cisco Systems
CDR none
Inbuilt FEC No
Receiver Min/Max -18 dBm / -3 dBm (overload)
SGMII No
Transmit Min/Max -10 dBm / 0 dBm
Power Consumption 1 W
Modulation NRZ
Industry Telecommunications, Carriers, Service and Content Providers, Campus Networks, Data Centres, Enterprise Networks
Applications Data Centre Connectivity, GPON (Gigabit Passive Optical Network), LAN Installation, Network Core and Edge, SFP/Transceiver Vendor Programming, RF and microwave photonics, Carriers, Service and Content Providers, Enterprise Networking
Standard Package Contains
Warranty 1 Year
Warranty Notes AusOptic Genuine Product Guarantee
Authorised distributor, benefit from manufacturer-backed, local warranty coverage, genuine parts, and our experienced local support team
