FLEXOPTIX 12G UHD Video SDI SFP+ with dual CDR | 10 km, λ1310 nm, LC-Duplex, Singlemode

SKU #P.1312G.10.RPS
  • Universal Video SFP+ Transceiver
  • Use FLEXBOX to configure to almost any vendor
  • 3G SDI protocol support for broadcasting applications
  • Integrated Clock-Data-Recovery (CDR)
  • Supported Data Rates: 270 Mbit/s - 11.88 Gbit/s
  • Up to 10 km via Singlemode OS2
  • LC-Duplex Connector
AU$594.70 AU$654.17
Reordering - Contact to confirm availability
Part Number
P.1312G.10.RPS
More Information
Manufacturer FLEXOPTIX
Product Series FLEXOPTIX Universal Transceivers
Product Type Transceivers
Form Factor SFP+
Connector LC-Duplex PC
Distance 10 km
Interface 12G UHD SDI
Wavelength TX 1310 nm
Power Budget (dB) 5.8 dB
Extinction Ratio 3.5 dB
Laser DFB
Receiver Type PIN
Type of DDM / DOM Yes, internally calibrated
Vendor Switch Coding MSA Standard
Modulation NRZ
CDR TX and RX
Inbuilt FEC No
Receiver Min/Max -14 dBm / 0.5 dBm (overload)
SGMII No
Transmit Min/Max -8.2 dBm / 2 dBm
Wavelength RX (Range) 1260 - 1620 nm
Power Consumption 1.5 W
Bandwidth Range 270 Mbit/s - 11.88 Gbit/s
Industry Telecommunications, Carriers, Service and Content Providers, Campus Networks, Data Centres, Enterprise Networks
Applications Data Centre Connectivity, GPON (Gigabit Passive Optical Network), LAN Installation, Network Core and Edge, SFP/Transceiver Vendor Programming, RF and microwave photonics, Carriers, Service and Content Providers, Enterprise Networking
Networking Protocol 12G UHD SDI
Temperature Range 0°C - 70°C
Standard Package Contains
Warranty 1 Year
Warranty Notes AusOptic Genuine Product Guarantee
Authorised distributor, benefit from manufacturer-backed, local warranty coverage, genuine parts, and our experienced local support team
