FLEXOPTIX 10G XFP LR Industrial with dual CDR | 20 km, λ1270 nm, LC-Duplex, Singlemode

SKU #X.B1696.20.ADI
  • Universal XFP Transceiver
  • Use FLEXBOX to configure to almost any vendor
  • For 10GBASE-LR Ethernet links
  • Integrated Clock-Data-Recovery (CDR)
  • Supported Data Rates: 9.95 Gbit/s - 11.3 Gbit/s
  • Up to 20 km via Singlemode OS2
  • LC-Duplex Connector
  • Operating Temperature from -40&C to 85&C
AU$217.70 AU$239.47
Reordering - Contact to confirm availability
Part Number
X.B1696.20.ADI
More Information
Manufacturer FLEXOPTIX
Product Series FLEXOPTIX Universal Transceivers
Product Type Transceivers
Form Factor XFP
Connector LC-Duplex PC
Distance 20 km
Interface LR
Wavelength TX 1270 nm
Power Budget (dB) 12 dB
Extinction Ratio 3.5 dB
Laser DFB
Receiver Type PIN
Type of DDM / DOM Yes, internally calibrated
Vendor Switch Coding MSA Standard
Modulation NRZ
CDR TX and RX
Inbuilt FEC No
Receiver Min/Max -14 dBm / 0.5 dBm (overload)
SGMII No
Transmit Min/Max -2 dBm / 3 dBm
Wavelength RX (Range) 1320 - 1340 nm
Power Consumption 2 W
Bandwidth Range 9.95 Gbit/s - 11.3 Gbit/s
Industry Telecommunications, Carriers, Service and Content Providers, Campus Networks, Data Centres, Enterprise Networks, Financial Institutions, Government and Defence Communications, Aerospace and Defence, Broadcast, Mining, Off-shore and Remote, Security, Transportation, Utilities
Applications GPON (Gigabit Passive Optical Network), Last Mile, LAN Installation, Network Infrastructure, Network Core and Edge
Networking Protocol 10G Ethernet, 8G Fibre Channel, 10G FC, OTU2, STM-64
Temperature Range -40°C - 85°C
Standard Package Contains
Warranty 1 Year
Warranty Notes AusOptic Genuine Product Guarantee
Authorised distributor, benefit from manufacturer-backed, local warranty coverage, genuine parts, and our experienced local support team
