FLEXOPTIX 100G QSFP28 LR4 Industrial with dual CDR | 10 km, λ1296-1309 nm, LC-Duplex, Singlemode

SKU #Q.161HG.10.I

Universal QSFP28 Transceiver
Use FLEXBOX to configure to almost any vendor
For 100GBASE-LR4 Ethernet links
Integrated Clock-Data-Recovery (CDR)
Supported Data Rates: 103.12 Gbit/s
Up to 10 km via Singlemode OS2
LC-Duplex Connector
Operating Temperature from -40°C to 85°C

AU$1,411.34 AU$1,552.47

Reordering - Contact to confirm availability

Part Number

Q.161HG.10.I

More Information
Manufacturer	FLEXOPTIX
Product Series	FLEXOPTIX Universal Transceivers
Product Type	Transceivers
Form Factor	QSFP28
Connector	LC-Duplex PC
Distance	10 km
Interface	LR4
Wavelength TX	1295.6 nm\|1300.1 nm\|1304.6 nm\|1309.1 nm
Power Budget (dB)	4.3 dB
Extinction Ratio	4 dB
Laser	DFB
Receiver Type	PIN
Type of DDM / DOM	Yes, internally calibrated
Vendor Switch Coding	MSA Standard, Cisco Systems, Extreme
Lane Count	4x (Tx/Rx)
Modulation	NRZ
CDR	TX and RX
Inbuilt FEC	No
Bandwidth Per Lane	25.78 Gbit/s
Receiver Min/Max	-8.6 dBm / 4.5 dBm (overload)
SGMII	No
Transmit Min/Max	-4.3 dBm / 4.5 dBm
Power Consumption	1.5 W
Bandwidth Range	103.12 Gbit/s
Industry	Telecommunications, Carriers, Service and Content Providers, Campus Networks, Data Centres, Enterprise Networks
Applications	Data Centre Connectivity, GPON (Gigabit Passive Optical Network), LAN Installation, Network Core and Edge, SFP/Transceiver Vendor Programming, RF and microwave photonics, Carriers, Service and Content Providers, Enterprise Networking
Networking Protocol	100G Ethernet
Temperature Range	-40°C - 85°C
Standard Package Contains
Warranty	1 Year
Warranty Notes	AusOptic Genuine Product Guarantee Authorised distributor, benefit from manufacturer-backed, local warranty coverage, genuine parts, and our experienced local support team
