EXFO LTB-2 Rackmount Modular Mainframe

SKU #LTB-2
The LTB-2 is a powerful, scalable, two-slot modular rackmount platform designed for optical and multi-service testing in central office/headend environments, data centres and DCI’s, and labs/manufacturers.
Request Quote
Request current lead time
Part Number
LTB-2

Features

  • Flexible, scalable and modular: Compact 1U modular solution with in-rack or tabletop applications. Features datacom and transport protocol testing and simultaneous testing of up to 4 x 100G
  • Hot swappable: Intelligent module hot-swap capability, enabling a quick transition from platform to platform, or from rackmount platform to portable platform without powering down
  • Industrial-grade computer design: Simple, easy-to-use design powered by a quad-core processor with the Microsoft Windows operating system
  • Out-of-band management: Optimal remote access for maintenance or initial setup using Intel® Active Management Technology (AMT)
  • Connectivity: USB 3.0, LAN, Sync and AMT port for maximum connectivity options
  • Accessibility: Remote access capability via VNC or Remote Desktop. Third-party tools can be easily installed for a versatile range of applications

Applications

  • Multiservice testing in labs
  • Central office re-architected as a data center (CORD)
  • Headend Re-architected as a data center (HERD)
  • Data center interconnect (DCI)

Description

Recognized as a best-in-class platform, the LTB-2 is a versatile solution addressing numerous transport and datacom applications. Whether in the central office/exchange, design lab or during the manufacturing process, the LTB-2 provides users with added testing versatility and power to take on the today’s complex challenges.

The Windows advantage

Keep it simple and use mainstream applications such as Microsoft Office Suite (i.e., Word, Excel and PowerPoint) and other familiar programs.

  • Faster start times and multitasking for a superior user experience
  • Familiar desktop design for ease of use
  • Connect remotely with Microsoft Remote Desktop and EXFO’s remote toolbox

Supports transport and datacom multiservice test modules

The FTBx-88260 is a customizable 1G-to-100G multiservice test module, built to handle multiple transceiver types via EXFO’s unique Open Transceiver System (OTS).

Key features:

  • Supported interfaces: copper SFP/SFP+, SFP, SFP+, SFP28, QSFP+, QSFP28, CFP4 and AOC cables
  • Ethernet testing including RFC 6349 and EXFO’s iSAM for 100G testing
  • 5G support CPRI/eCPRI, including eCPRI 10G and 25G

The FTBx-8870/8880 Power Blazer are versatile, 10G multiservice test modules.

Key features:
  • Dual-port, Ethernet-testing capability—up to 10GE
  • Testing of speeds from 1.5M to 10G
  • Covering multiple technologies: OTN, SONET/SDH, DSn/PDH, Ethernet, Fibre Channel and CPRI

Remote monitoring and control

Use remote access applications such as Java, VNC, remote desktop or web browsers to monitor and troubleshoot test applications carried out on an LTB-2 platform found anywhere.

Get connected and share resources

EXFO TFv—Test Function Virtualization is the industry’s first suite that focuses on test function virtualization. This suite is ideal for lab managers who are looking to scale their testing requirements to specific user needs.

  • FTB Anywhere floating test licenses enable EXFO’s platform users to share licenses, giving them the functionality that they need anytime, anywhere. Customers own the software licenses and can share them between platforms.
  • FTB OnDemand time-based licenses activate a wide range of test functionalities for a specific period of time—perfect when a test function is only needed for a specific project.
More Information
Manufacturer EXFO
Product Series EXFO LTB-2 Rackmount Modular Mainframe
Product Type Modular Test Platforms
Industry Telecommunications, Carriers, Service and Content Providers, Optical Equipment Manufacturing (OEM), Photonics, Research
Applications Multi-Layer Network Field Testing, OTDR Testing & Fiber Characterisation, System Emulation (Loss, length, time delay and reflectance), OEM (Optical Equipment Manufacturing), Active and passive component testing, High-Yield Manufacturing, Multiple Application Platform (MAP) Chassis, Manufacturing/Industry 4.0, PIC wafer-level testing, Sensing and spectroscopy, Spectral characterisation, System verification and design, Transceiver manufacturing, WSS and ROADM calibration and tests
Operating Temp. (Min) 0°C
Operating Temp. (Max) 50°C
Standard Package Contains
Warranty Notes AusOptic Genuine Product Guarantee
Authorised distributor, benefit from manufacturer-backed, local warranty coverage, genuine parts, and our experienced local support team
