Miller ACS 2 Armoured Cable Slitter

SKU #262019 | MFR #37897
ACS2 Armoured Cable Slitter for corrugated copper, steel or aluminum armor layer on Fibre Feeder, Central Tube, Stranded Loose Tube fibre optic cables.
AU$239.75 AU$263.73
Typically Ships in 15 to 20 Business Days
Part Number
262019

ACS 2

Armored Cable Slitter

  • Professional grade tool ideal for slitting the corrugated copper, steel or aluminum armor layer on Fiber Feeder, Central Tube, Stranded Loose Tube fiber optic cables and other armored cables
  • Versatile design allows jacket or shield slitting on non-fiber optic cables as well
  • Tool slits outer polyethylene jacket and armor in one operation

– Performs longitudinal slitting and circumferential (ringing) for end stripping

– Blade rotates 90 degrees by activating blade lever, allowing easy mid-span preparation (ringing and slitting)

  • ACS 2 is adjustable from 0.157 in. (4 mm) to .393 in. (10 mm) for smaller cable O.D. options
  • Adjustable blade depth to 5.5 mm maximum to accommodate different cable jackets
  • Cable guide wheel provides cable stability and allows for easier tool movement along the cable
  • Rugged anodized aluminum and steel construction
  • Cable guide wheel for smaller cable sizes can be ordered separately



Specification

Made in the U.S.A.

Height: 5 in (127 mm)

Weight: 10 oz (284 g)





More Information
Manufacturer Miller
Manufacturer Part Number 37897
Barcode 856848006847
Warranty Notes AusOptic Genuine Product Guarantee
Authorised distributor, benefit from manufacturer-backed, local warranty coverage, genuine parts, and our experienced local support team
