Miller ACS 2 Armoured Cable Slitter

ACS 2

Armored Cable Slitter

• Professional grade tool ideal for slitting the corrugated copper, steel or aluminum armor layer on Fiber Feeder, Central Tube, Stranded Loose Tube fiber optic cables and other armored cables
• Versatile design allows jacket or shield slitting on non-fiber optic cables as well
• Tool slits outer polyethylene jacket and armor in one operation

– Performs longitudinal slitting and circumferential (ringing) for end stripping

– Blade rotates 90 degrees by activating blade lever, allowing easy mid-span preparation (ringing and slitting)

• ACS 2 is adjustable from 0.157 in. (4 mm) to .393 in. (10 mm) for smaller cable O.D. options
• Adjustable blade depth to 5.5 mm maximum to accommodate different cable jackets
• Cable guide wheel provides cable stability and allows for easier tool movement along the cable
• Rugged anodized aluminum and steel construction
• Cable guide wheel for smaller cable sizes can be ordered separately

Specification

Made in the U.S.A.

Height: 5 in (127 mm)

Weight: 10 oz (284 g)
