1Cure-201 Intelligent Curing Oven

SKU #1Cure-201
High performance curing oven for MPO and single fiber, designed for both vertical and horizontal applications. With an extensive selection of over 999 customizable curing profiles, the 1Cure stands out as the most intelligent and versatile curing oven on the market.
Request Quote
Request current lead time
Part Number
1Cure-201

Features

  • Applications Include; MT(MPO),LC, SC, ST, FC, MU, SMA, VSFF Connectors, Uniboot LC, Mil-Aero Termini and much more.
  • Step-Cure Capable (Ramp & Soak Programmable)
  • MT or Single-Fiber curing
  • Flat to Angled internal tilt for Horizontal Curing
  • Integrated Thermocouple in fixture for ideal calibration
  • Networkable
  • Touch screen interface
  • Up to 999 programmable cure schedules
  • Temperature Range +5°C to 155°C
  • Temperature Display Resolution 4 digit / 0.1°C
  • Temperature Uniformity +/-2°C
  • Temperature Accuracy +/-2 ° C
  • Horizontal Positions for Curing Flat 0° / Upward +15°/ Downward -15°
  • Curing Vertical Curing Capacity 72 ports
  • Horizontal Curing Capacity 24 MT, 36 LC

Ramp Curing to Prevent Fiber Cracking in Multi-Fiber or Large Core Fibers

Curing Profiles

Curing profiles can be designed to ramp up, soak, and ramp down in single or multiple steps.

Standardize on One Epoxy

It is recommended to use a single epoxy for consistency.

Remote Monitoring and Programming

Ovens can be remotely monitored and programmed.

Precision Temperature Control

Ensure precise temperature control during the curing process.

Convertible Lid for Vertical Curing

A convertible lid allows for vertical curing using blocks.

Custom Trays and Blocks

Custom trays and blocks are available upon request.

Password Protected User Mode

A password-protected user mode ensures security.

4.3" Color Touchscreen Interface

The interface features a user-friendly 4.3" color touchscreen.

Alerts and Notifications

Receive alerts and notifications via text or email when a cycle is complete.

Audit Trail

All user actions and alarms are recorded in an audit file.

User-Friendly Interface

The interface is designed with user-friendly icons and menus.

Multilingual Support

The system supports up to 27 different languages.

Made in the U.S.A.

The product is proudly made in the U.S.A.

C.E. Certified for Sale in the European Union

The product is C.E. certified for sale in the European Union.


Introducing the 1Cure: The Ultimate Epoxy Curing Oven

The 1Cure is an epoxy curing oven designed for both vertical and horizontal applications. With its advanced technology and cutting-edge features, the 1Cure stands out as the most intelligent and versatile curing oven in the market.

Precise Heating Control for Optimal Results

Unlike traditional ovens that can only monitor the hot plate temperature, the 1Cure has the unique ability to monitor and precisely control the heating surface in contact with a connector. This innovative approach ensures optimal curing results and minimizes the risk of overheating or under heating.

Customization Options for Specific Requirements.

The 1Cure offers a wide range of customization options, with over 999 curing profiles that can be tailored to specific requirements. By utilizing the ramp-soak feature, the 1Cure enhances cross-linking and reduces stress in multimode and MT style connectors, resulting in superior performance and durability.

Accommodating Connector Technologies

To further accommodate the ever-evolving connector technologies, the 1Cure is available with a variety of fixtures and cabling handling solutions. Whether you are working with existing connectors or emerging technologies, the 1Cure has you covered.

Trust the 1Cure for Unmatched Precision, Versatility, and Reliability

Trust the 1Cure for all your epoxy curing needs and experience unmatched precision, versatility, and reliability. The 1Cure is the ultimate solution for achieving superior curing results in a wide range of applications.

More Information
Manufacturer 1Cure
Product Series 1Cure Epoxy Curing Ovens
Product Type Epoxy Curing Ovens
Size / Operation Benchtop
Device Connectivity via USB
Industry Aerospace and Defence, Optical Equipment Manufacturing (OEM)
Applications Cable Assembly Fabrication
Standard Package Contains
Warranty 1 Year
Warranty Notes AusOptic Genuine Product Guarantee
Authorised distributor, benefit from manufacturer-backed, local warranty coverage, genuine parts, and our experienced local support team
